Hydraulic Shearing Machine is a highly efficient metal shear machine used for cutting various metals, such as steel, stainless steel, aluminum and other materials. It features a powerful hydraulic system, with a working pressure of 8-12Mpa, which ensures a smooth and accurate cutting of metal sheet. The main motor is 7.5KW, and the cutting angle is adjustable from 1.5°. It is equipped with a high-quality blade made of Cr12 material, and its overall dimensions are 4000x1600x1700mm. This hydraulic swing beam shearing machine can provide an efficient and accurate shearing solution for various materials. It is also equipped with a CNC system, which enables for precise cutting. This hydraulic metal shear machine is suitable for a variety of applications such as sheet metal processing, automobile manufacturing, shipbuilding, metalworking and more.
| Name | Specification |
|---|---|
| Product Name | Single Cutting Continuous Cutting Hydraulic Shearing Machine |
| Blade Material | Cr12 |
| Cutting Angle | 1.5° |
| Working Pressure | 8-12Mpa |
| Weight | 4500Kg |
| Control System | PLC |
| Back Gauge Range | 0-1000mm |
| Blade Clearance Adjustment | Manual |
| Stroke Adjustment | Manual |
| Cutting Width | 3000mm |
Hydraulic shearing machine is a kind of CNC hydraulic shearing machine, which is mainly used to cut thin plates with thickness range from 1mm to 25mm. It is composed of hydraulic swing beam shearing machine and CNC system. The overall dimensions of the machine is 4000x1600x1700mm, and the main motor power is 7.5KW. The blade material of the machine is Cr12. The back gauge range of the machine is 0-1000mm, which makes it possible for cutting plates in different sizes. This machine is widely used in metal processing industry and it is suitable for cutting sheet metal, copper plates, aluminum plates, stainless steel plates and other metal plates.
We offer comprehensive technical support and service for our Hydraulic Shearing Machine. Our team of experienced technicians is available 24/7 to answer questions and address any issues or concerns you may have. We can troubleshoot issues with the unit, provide preventive maintenance advice, and offer suggestions on how to optimize your shearing machine for maximum efficiency.
In addition to troubleshooting and preventive maintenance, our team can provide repair and replacement services for parts and components of the machine. We can also provide parts and accessories for upgrades and modifications to existing equipment. Our technicians also offer training and instruction in the use of the machine, as well as how to properly maintain it.
If you have any questions or are in need of technical support or service for your Hydraulic Shearing Machine, please don't hesitate to contact us. We are here to help!
The Hydraulic Shearing Machine will be packaged in a custom wooden box designed for maximum protection during shipping. The box is made of durable plywood and is designed to withstand rough handling. The Hydraulic Shearing Machine is securely fastened inside the box with foam padding and straps. The box also contains a user manual and other accessories.
The Hydraulic Shearing Machine is shipped via a trusted freight carrier. The shipping cost will depend on the destination and the size of the package. We can also provide door-to-door delivery service for an additional fee.
Our products are sold all over the world, you can rest assured.
