Manual Roll V Grooving Machine Sheet Metal Shear H4C Control System
supply CNC sheet V grooving machine, V groover,V cutting machine
CNC V grooving machine describle
This equipment is fully CNC V Groover Machine for metal sheet. It adopts advanced CNC system and innovative design with the advantages of high processing precision, simple operation, no noise, no vibration
and so on. It is widely used in the sheet metal V-groove, U-groove and other irregular groove processing (including stainless steel, aluminum, aluminum plate, copper, iron, plastic, wood, acrylic panels and other special plates.). Particularly, it is applicable to the V-groove processing
of sheet metal before bending .
sheet V groovign machine parameter
|Max. width of steel sheet to be notched:
|Max. length of steel sheet to be notched
|Maximum thickness of steel sheet to be notched:
|Min. thickness of steel sheet to be notched
|Max. distance of the rear fedding
|Resolution of blade beam movement
|Max. speed of cutting
|Max. distance of tool carrier movement (up & down)
|Resolution of distance tool carrier movement
|Max. distance of sliding frame movement
|Work-piece error within 3200mm
|Min. distance of V-trough edge
|The motor of blade bean( left & right moveing)
|The gas path pressure range
3mm sheet v groovign machine Contrusction
The equipment adopts the big pitched ball screw and high torqued servo motors as the main drive, which makes knives more stable and faster when processing.
The worktable of high strong plate as the surface makes the workpieces not easy to wear in machining.
A panel with the adjustable fuselage during the workpiece activities makes the point to every bit of mesa precision in 0.02 mm distance that within.
Equipment which adopts PLC man-machine interface programming allows
the operating personnel easy to understand and locate accurately.
Components and parts
Hydraulic system: H4C DELTA Taiwang
servo motor: DELTA Taiang
Electrics: Germany Schnerdei/Omron;
ball screw: HINWING Taiwang
linear guide: HINWING Taiwang
cooling system: Beiqier Germany
Motor: SEW Germany
pneumatic compents: AIRTAC Germany
Before shipment we will install and adjust the machine,make the test run to
keep everything is going well.When the machine is ready in customer's factory,
if you need our assistance,we could arrange our engineeer to your factory,to hel
and teach your worker how to operate the machine.The guarantee is 1 year.During
the period,if the machine is broken due to its quality problem,we could send the electrical
parts with free.
the feeding unit of stainless steel on the 6mm CNC sheet V grooving machine.
